The Mexican practice Dellekamp Arquitectos inaugurates this weekend in Alameda Central, Mexico City and for the second time (the first was in the Forest of Chapultepec), on the occasion of the celebration of the 70 years of diplomatic relations between Switzerland and Mexico, the Pavilion Casa de Suiza.

Coinciding with the celebration of the Mextrópoli festival, Casa de Suiza, designed by Dellekamp Arquitectos, is a wooden pavilion (the material that makes reference to the typical Swiss houses), that thanks to its prefabricated and flexible structure based on a triangular grid, becomes a fleeting ephemeral pavilion, adaptable to different sites. Located initially in the Bosque de Chapultepec, now within the framework of the Festival internacional Mextrópoli, with some modifications, it has been moved to the Alameda Central.


Description of project by Dellekamp Arquitectos

ORIGEN

Casa de Suiza Pavilion comes with the celebration of the seventy years of diplomatic relations between Switzerland and Mexico. It is set in “El Bosque de Chapultepec” landmark, the heart of Mexico City and America’s oldest city park.

Dellekamp Arquitectos began to work on the project without a defined program and site, so a modular system was designed based on a triangular grid that allows adaptation to different sites and changing needs of program, which allowed transformations during design process. This adaptability feature allows it to be roaming and can go to multiple sites without damaging the environment.

Its first location was in "El Bosque de Chapultepec", emblematic place, heart of Mexico City and oldest urban park of America. This weekend, a fragment of this is placed in the Alameda Central within the framework of the International Festival Mextrópoli.

MATERIALITY

The design of Casa de Suiza abides to the materiality of the original House of Switzerland made entirely of wood, a traditional way of building in Switzerland. The pavilion is designed in modules made of certified pine wood and metal joints, promoting the use of wood as a structural material in Mexico. These modules are derived from the triangular grid, which guarantees and efficient assembly and disassembly of the structure on site. Prefabrication and assembly are carried out by the company “Metal y Madera”.

PROJECT FACE TO TAMAYO

The pavilion has two levels; the ground floor will have a height of 2.70 m. and the upper floor 3.30 m., for a maximum height of 6.5 m. Its length is 32 m. wide by 18 m. deep, with a rebuff of 343 m² and a total of 571 m².

On the ground floor is composed by an open forum, two thematic exhibitions, commerce and basic services; the upper floor has three showrooms.

PROJECT IN LA ALAMEDA

The pavilion will have two levels; Its maximum height is 6 m, with a front extension of 18.30 m, 11.5 m deep. The total of built meters is 171 m², unlike the first pavilion this will be an open space without internal divisions, has an open forum for cultural events and on its upper floor a circulation that works as a viewpoint.

SUSTAINABILITY

In addition to the use of wood as a renewable and sustainable material construction, the pavilion offers an alternative to water management.

Rainwater is collected through a siphon system strainers. This water is made drinkable and used in sinks. The sewage is treated and then used in toilets, so there is a constant cycle of water reuse; both actions are reflected in a minimum expenditure of potable water.

Read more
Read less

More information

Label
Architects
Text
Dellekamp Arquitectos | Derek Dellekamp & Jachen Schleich + Andrés Palomino



+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Project leader
Text
Jachen Schleich
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Team
Text
José Manuel Estrada, Alice Seban, Gustavo Hernández, Eduardo Cabral, Benoist Rouel-Brax, Laura Alonso, Antoine Vaxelaire, Javier Ramírez, Valentina Sánchez
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Builder
Text
Metal y Madera
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Structural design
Text
Ingeniería Estructural (Oscar Trejo)
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Supplies design (Bosque de Chapultepec)
Text
Power desgin.- Ubaldo Velázquez;
Pluvial installation.- 3P Technik Mexico;
High efficiency hydraulic system.- Spl;
Lighting Design.- Luz en Arquitectura
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Location
Text
1st location.- Bosque de Chapultepec, Mexico City, Mexico;
2nd location.- Alameda Central, Mexico City, Mexico
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Estatus
Text
Completed
+ + copy Created with Sketch.
- + copy Created with Sketch.
Dellekamp + Schleich is an architectural firm based in Mexico City, founded in 1999 as Dellekamp Arquitectos by Derek Dellekamp, an architect from the Universidad Iberoamericana, Mexico City, Mexico (1992-1997). The studio was renamed Dellekamp + Schleich with the addition of the architect Jachen Duri Schleich as co-director. The studio is dedicated to the design and supervision of architectural projects of any scale or program through a rigorous research methodology. They study each case to find precise solutions to the different realities in this way we maximize the intentions of budget, image, use, context, and emotion of each project.

Dellekamp + Schleich is dedicated to the development and supervision of architectural projects regardless of scale or program type with a rigorous research methodology. They aim to find unique solutions to the specific conditions of each project in order to maximize its intended budget, image, use, context, and spirit. The coordination and collaboration with various disciplines such as engineering, graphic design, industrial design, environmental engineering, and landscape architecture make up a significant part of their activities, adding value to their team of specialists focused on the accomplishment of integral solutions. Simultaneously, Dellekamp Arquitectos is involved in ongoing architectural research that fosters a laboratory of ideas that can feed our activities. This way, they are constantly a part of the academic and teaching realms, as well as research studies, lectures, publications, biennales, and exhibitions.

Since 2005, Derek Dellekamp has been a professor at the faculty of Architecture at the Universidad Iberoamericana and the Universidad Anáhuac. He is also an Invited Professor at Rice School of Architecture in Houston, USA at the University of Texas. In 2014 he was invited as a visiting critic to the workshop at the Harvard University’s Graduate School of Design.

Void Temple of Pilgrim Route was selected from over 200 participants from around the world, as Highly Commended in the AR Awards for Emerging Architecture 2014 held in London in late 2013. 1st prize in XIX CEMEX BUILDING AWARD in Urbanism category 2010; Ruta del Peregrino has been selected to be part of the Collection of Architecture of the Centre Pompidou in Paris 2010; Winner of CAM-SAM Award Bicentenario al Merito Profesional y Jovenes Arquitectos in Architecture category 2010; Silver Medal for Tlacolula at XI Mexican Biennale in Social Housing category 2010; First place in Sully competition, a proposal curated by Christ & Gantenbein and done in conjunction with a team of international architects in 2010; Earned the scholarship FONCA for his research project of social housing in Mexico 2010; World Architecture Community Awards 3rd cycle, CB30 apartment building 2009; The International Architecture Awards 2008, CB29| CB30 apartment building 2008; Wallpaper Architects Directory 2007; 101 of the world’s most exciting new architects 2007; 1st place in the Chapultepec Educational | Environmental Park, Chapultepec, Mexico City, Mexico, Derek Dellekamp and TOA taller 2004; Honorary Distinction in the VIII Architecture Biennal Mexico, AR58 apartment building 2004; Honorary Distinction in Jose Vasconcelos National Library Competition in collaboration with Dominique Perrault, Michel Rojkind and Miquel Adria 2003.

Jachen Duri Schleich graduated in architecture from ETH Zurich, 2006. He has Master in Science from ETH, 2006.
Read more
Published on: March 12, 2017
